2024 Ferrari 499P
Chassis no.
499P 12 24 P
Engine no.
F163CG DM05
Coachbuilder
Ferrari
Beacon
ON/OFF
ON/OFF
Chassis
From February 2024
Chassis 499P 12 24 P
Dampers Adjustable Type
Disc Brakes Vacuum-operated assistance
Disc Brakes Front / Rear
Front Suspension Unequal double wishbones and coil springs
Manufacturer FERRARI SPA
Notes Chassis Carbon fiber monocoque designed by Ferrari, with composite components manufactured by Dallara. Wheelbase and track widths have not been disclosed; the project complies with LMH limits (overall length max 5000 mm; width max 2000 mm; wheelbase ≤ 3150 mm).
Notes Brakes Ventilated Carbon Discs
Notes Suspension PKM
Chassis Frame Unibody
Rears Suspension Unequal double wishbones and coil springs
Technical Specifications and History Y
Engine
From February 2024
Alternative engine Fitted with front-axle electric motor-generator unit (Compact Dynamics project, unit n° B003) delivering 200 kW (272 hp), powered by a 900-volt lithium-ion battery pack that recharges mainly through regenerative braking and deceleration phases. It engages above the FIA-imposed speed threshold, creating a temporary all-wheel-drive system that works in combination with the rear-mounted combustion engine. The integration of the two units provides balance and efficiency, with overall output capped at 500 kW by regulation.
Arrangement V-Type
Bore 88 mm
Stroke 82 mm
Cooling System Water Cooled
Cubic displacement 2992 cc
Cylinders 6
Electrical equipment Volt 12
Engine F163CG DM05
Engine Type Mid
Final drive Hypoid type
Fuel System Injection type Direct fuel injection. Bosch Motorsport MS7
Gearbox Number of forward speed 7
LSD Y
Manufacturer FERRARI SPA
Maximum power 680 hp
Maximum torque 76 kgm
Maximum torque 6500 rpm
Notes Fuel System Twin parallel turbochargers in hot-vee configuration
Notes Gearbox X trac 1377 n. 014 sequential gearbox with electro-actuated paddle shift, carbon clutch
Notes Engine Hybrid powertrain: internal combustion engine, 120° V6 derived from Ferrari 296 GT3. Serves as a structural element of the carbon fiber monocoque.
Supercharged Y
Technical Specifications and History Y
Top speed 343 Km/h
Transmission Clutch Dry dual disc Hydraulic
Fuel Type Petrol-Gasoline
Valves per cylinder 4
Valvetrain DOHC
Transmission Wheel drive Four wheel drive
Body
From 2024
Coachbuilder Ferrari
Colour Red
Wheels type Alloy
Designer Manzoni
Material Full carbon-fiber composite bodywork
Notes body The livery is a nod to the 2024 official Ferrari racing livery. The shade chosen—Rosso Racing— is the same used in F1 and different from "Rosso Le Mans" shade used in 2023. Configuration: racing no. #50/2024, to celebrate the successes of Ferrari’s Hypercar program at Le Mans with cars #50 and #51.
Number of doors 2
Number of wheels 4
Type of body Sport and Barchetta
Tyres Front size 29/71-18
Tyres Rear size 34/71-18
Unladen weight 1030 kg
Wheels Front size 12.5 x 18 ET23.5
Wheels Rear size 14 x 18 ET51.2
Previous Bodies View all (1)
Historical Body
From February 2024
Coachbuilder Ferrari
Colour Unknown testing livery
Wheels type Alloy
Designer Manzoni
Material Full carbon-fiber composite bodywork
Notes body Developed by Ferrari’s in-house engineering dept. under the direction of Ferdinando Cannizzo, refined by the Centro Stile Ferrari led by Flavio Manzoni. Triple-plane rear wing, optimized underbody flows. Lightweight removable panels for a quick access to mechanical components. Cooling ducts integrated into the sidepods and engine cover.
Number of doors 2
Number of wheels 4
Other colour Unknown testing livery
Type of body Sport and Barchetta
Tyres Front size 29/71-18
Tyres Rear size 34/71-18
Unladen weight 1030 kg
Wheels Front size 12.5 x 18 ET23.5
Wheels Rear size 14 x 18 ET51.2
Interior
From February 2024
Cockpit/panels Grey
Hand drive CHD - Central Hand Drive
Material Carbon-fibre
Number of seats 1
Seats Grey
