1985 Lancia Delta S4 Corsa

From  1985

Chassis  *ZLA038AR0*00000 207*

Dampers  Telescopic Type

Disc Brakes  Vacuum-operated assistance

Disc Brakes  Front / Rear

Front Suspension  Unequal double wishbones and coil springs

Fuel tank capacity  80 litre

Chassis Frame  Tubular Spaceframe

Rears Suspension  Unequal double wishbones and coil springs

Steering  Rack and pinion

Technical Specifications and History  Y

Online  Y - E' visibile

Wheel track front  1510 mm

Wheel track rear  1535 mm

Wheelbase  2440 mm

From  1985

Arrangement  Inline

Bore  88 mm

Stroke  71 mm

Compression Ratio  7 : 1

Cooling System  Water Cooled

Cubic displacement  1759 cc

Cylinders  4

Electrical equipment Volt  12

Engine  233ATR18S1068

Engine Type  Mid

Fuel System Injection type  Weber Magneti Marelli IAW

Gearbox Number of forward speed  5

LSD  Y

Manufacturer  ABARTH & C. SPA

Maximum power  480 hp

Maximum power  8400 rpm

Maximum torque  50 kgm

Maximum torque  5000 rpm

Notes Fuel System  Twin supercharger: Turbocharger KKK K27 and Volumetric charger Abarth Volumex R18/2

Notes Gearbox  Frontal Grafts

Notes Engine  aluminium block,

Supercharged  Y

Technical Specifications and History  Y

Fuel Type  Petrol-Gasoline

Valves per cylinder  4

Valvetrain  DOHC

Transmission Wheel drive  Four wheel drive

From  1985

Coachbuilder  Abarth

Colour  White

Wheels type  Alloy

Height  1360 mm

Lenghth  4092 mm

Material  carbon fibre composite

Number of doors  2

Number of wheels  4

Type of body  Two-door saloon

Unladen weight  950 kg

Wheels Front size  16

Wheels Rear size  16

Width  1880 mm

From  1985

Cockpit/panels  Black

Hand drive  LHD - Left Hand Drive

Number of seats  2

Seats  Black
